Network Standard
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
IPv4
IPv6
Processor
1.5 GHz tri-core processor
Boosts speed
OFDMA (Orthogonal Frequency Division Multiple Access)
1024-QAM high data rate
20/40/80/160 MHz bandwidth
Ports
RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 3
Package content
ZenWiFi XD6
RJ-45 cable
Power adapter
Warranty card
Quick start guide
Remark
Content may vary in different regions and packages.
AiProtection
AiProtection : AiProtection Pro
Router Security Assessment : 有
Malicious site blocking : 有
Two-Way IPS : 有
Infected Device Prevention and Blocking : 有
Traffic Control
Adaptive QoS : 有
Bandwidth Monitor : 有
Bandwidth limiter : 有
Maximum Bandwidth limiter rule : 32
Traditional QoS : Yes
Maximum Traditional QoS rule : 32
Traffic Monitor : 有
Real-time traffic monitor : 有
Wired Traffic Monitor : 有
Wireless Traffic Monitor : 有
Traffic Analyzer : 有
Website history : 有
WAN
Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP
Dual WAN : 有
WAN Aggregation : 無
3G/4G LTE dongle : 無
Android tethering : 無
Port forwarding : 有
Maximum port forwarding rule : 64
Port triggering : 有
DMZ : 有
DDNS : 有
Let's Encrypt : 有
VPN
VPN Client L2PT : 有
VPN Client OVPN : 有
VPN Client PPTP : 有
VPN Server IPSec : 有
VPN Server OVPN : 有
VPN Server PPTP : 有
VPN Fusion : 無
Administration
Operating mode : Wireless router mode
Range extender mode
Access point mode
Media bridge mode
Operating system : ASUSWRT
Free OS upgrade : 有
Firewall : 有
Maximum Firewall keyword filter : 64
Maximum Firewall network service filter : 32
Maximum Firewall URL filter : 64
Wake on LAN (WOL) : 有
SSH : 有
Configuration backup and restore : 有
Diagnosis tools : 有
Feedback system : 有
System log : 有
