網路技術標準
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, IPv4, IPv6
-
產品分類
AX 3000 (2402Mbps+574Mbps)
-
涵蓋範圍
大坪數
-
傳輸量
802.11a : 6,9,12,18,24,36,48,54 Mbps
802.11b : 1, 2, 5.5, 11 Mbps
802.11g : 6,9,12,18,24,36,48,54 Mbps
802.11n : up to 300 Mbps
802.11ac : up to 867 Mbps
802.11ax (2.4GHz) : up to 574 Mbps
802.11ax (5GHz) : up to 2402 Mbps
-
天線
外部 天線 x 4
-
Transmit/Receive
2.4 GHz 2 x 2
5 GHz 2 x 2
-
處理器
1.5 GHz tri-core processor
-
記憶體
256 MB Flash
512 MB RAM
-
Wi-Fi 技術
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
1024-QAM high data rate
20/40/80/160 MHz bandwidth
-
運作頻率
2.4 GHz / 5 GHz
-
加密模式
WPA3-PSK, WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , WPA3-Enterprise, 支援 WPS
-
防火牆與進階功能
Firewall: SPI intrusion detection, DoS protection
Access control:Parental control, Network service filter, URL filter, Port filter
-
管理程式
UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Port Forwarding, DMZ, System Event Log
-
VPN支援功能
IPSec Pass-Through
PPTP Pass-Through
L2TP Pass-Through
PPTP server
OpenVPN server
PPTP client
L2TP client
OpenVPN client
-
連線類型
網路連線類型 : 浮動 IP, 固定 IP, PPPoE(支援 MPPE), PPTP, L2TP
-
網路埠規格
RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 4
USB 3.1 Gen 1 x 1
-
功能
Router app
MU-MIMO
Traffic Analyzer
Adaptive QoS
AiProtection Pro
Parental Control
Guest Network :
VPN server : PPTP Server, IPSec server
VPN client : PPTP client, L2TP client, OpenVPN client
NAT Pass-Through :PPTP Pass-Through, L2TP Pass-Through, IPSec Pass-Through,
RTSP Pass-Through, H.323 Pass-Through, SIP Pass-Through, PPPoE relay
Mac OS Backup
Enhanced media server (AiPlayer app compatible)
- Image : Jpeg
- Audio : mp3, wma, wav, pcm, mp4, lpcm, ogg
- Video : asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, mov
AiCloud personal cloud service
3G/4G data sharing
Printer Server
- Multifunctional printer support (Windows only)
- LPR protocol support
Download Master
- Support bt, nzb, http, ed2k
- Support encryption, DHT, PEX and magnet link
- Upload and download bandwidth control
- Download scheduling
AiDisk file server
- Samba and FTP server with account management
IPTV support
Roaming Assist
OFDMA
Beamforming
-
按鈕
WPS Button, Reset Button, Power Switch
-
LED 指示燈
Power x 1
2.4G x 1
5G x 1
LAN x 4
WAN x 1
-
電源規格
AC 輸入: 110V~240V(50~60Hz)
DC 輸出:19 V 最大1.75 A 電流
-
作業系統支援
WindowsR 10
WindowsR 8
WindowsR 7
Mac OS X 10.6
Mac OS X 10.7
Mac OS X 10.8
-
產品尺寸
224 x 154 x 160 mm (長x寬x高)
-
重量
-
Operation mode
Wireless router mode
Access point mode
Media bridge mode
