CPU |
Intel CE5335 1.6GHz CPU (Dual-Core) |
Hardware Transcoding Engine |
H.264 (AVC), MPEG-4 Part 2, MPEG-2, VC-1 |
RAM |
1GB DDR3 |
Flash |
4GB eMMC |
No. of International Hard Drives |
2 x 2.5” or 2 x 3.5” SSD or hard drives
- Maximum Raw Capacity: 8TB
- The system is shipped without hard drives
|
Swappable Hard Drive |
2 x Hot-swappable hard drives |
Gigabit LAN |
1 |
LED Indicator |
STATUS, LAN, USB, HDD 1, HDD 2 |
USB Port |
2 x USB 3.0 port
2 x USB 2.0 port |
HDMI |
1 (Reserved) |
S/PDIF |
1 (Reserved) |
Button |
Power, Reset, USB one-touch-copy |
Form Factor |
Tower |
Dimension (mm) |
168.5 (H) x 102 (W) x 225 (D) mm |
Weight (Kg) |
Net weight: 1.28 kg
Gross weight: 2.32 kg |
Power Consumption (W) |
Sleep mode: 12.64 W
In operation: 23.61 W |
Temperature |
0 - 40?C |
Humidity |
5~95% RH non-condensing, wet bulb: 27?C |
Power Adaptor |
External Power Adaptor, 60W, 100-240V |
Max No. of Users |
2,048 |
Max No. of Network Shares |
256 |
Max No. of Concurrent Connections |
256 |
IP Camera Support |
2 free licenses included, upgradeable to 16 |
